3HP Pure Titanium Evaporator, Heat Exchanger, Titanium Gun, Sea Water And Freshwater Fish Pond Chiller Ice Bucket Radiator.

QUELECO Titanium Tube Cooling Coil Evaporator Heat Exchanger for 3HP Aquarium Chiller Fish Tank Seafood PondItem: QG-030TBCapacity: 3.0 HPMaterial: Pure titanium tubeTube Size: OD5/8 × 13.5 turnsRefrigerant Inlet: Flare nuts 1/2 (12.7mm)Refrigerant Outlet: Flare nuts 5/8 (16mm)Dimension: 18.7×5.9×14.6 (475×150×370mm)Working Condition:Water side (In your tank): seawater, salt water, brine water, nature water, drink water...Refrigerant side(In the tube): R22, R134a, R407c, R410a...Design Temperature of Tube Side: 100.4°F (38°C)Design Pressure of Tube Side: 203Psi (1.4Mpa)Test Pressure of Tube Side: 233.5Psi (1.61Mpa) 【By Your Request】Our cooling coil can be customized in dimension, connector, and capacity. If you have any special requirements, please let us know. 【Material】Our aquarium evaporator uses 99.99% pure titanium tubes as thermal conductors, its anti-corrosion function will save you more costs for product repair and maintenance. 【Medium】Refrigerant side(In the tube): R22, R134a, R407c, R410a...Water side (In your tank): seawater, salt water, brine water, nature water, drink water 【Warranty】Our aquarium heat exchanger has a 1-year warranty. If you have any questions about the product, please feel free to contact us.
